Saturday, August 8, 2020

8042 Progress photos

During the past 3 weeks work on Philadelphia 80 hundred car 8042 has progressed primarily with the finalizing of the dash apron pieces installation and the removal of all the structure from the rear of the car below the bonnet and above the bumper.  Keith made a short trip home to his shop to make new crown beam and floor frame for the rear of the car.
On his return on July 31 he proceeded to remove the side panel at the rear of the car so that he could tackle the structural needs on the blind side of the car at the rear bolster.  Below is the before and above is the after.  The photos that follow show a variety of decay found inside the car's 97 year old frame.

Add caption

Keith's plans are to rebuild this section, which is the only bolster end that was not addressed in past work on the car.

This is a closeup of the sill where the heater ground comes through the floor inside a conduit to connect to the frame of the car



This is a close up of the bolster end casting.  Behind the sill was three ft. piece of angle that reinforces the sill at the bolster attachment point.  Keith removed this and the casting inserted between the angle steel to reinforce the connection with a joint that is bolted in two directions.
This is the angle removed from the sill at the bolster







Shelving is in for now on the wall next to the car.  I rebuit this workbench from so that the space underneath could be used more effectively for the storage of parts.
We were very fortunate that Art could come down for a day and re-connect the air system components o the front platform.  He tried to blow air through the pipes to clean out the system, but to no avail.

Saturday, August 1, 2020

FairgroundsCanopyRoof–94 & 5 swap–94 windows!


The secret of removing the Shaker car's windows was revealed with a visit and demo from Bob , assisted by Ned this past Thursday (July 30).  This was a great mystery and we experimented with many things before Bob came down from Cleveland and showed the way.  The guys took three really clouded windows back home to start restoring them.


Ned and Bob show off the windows removed.

Inside the TDB Kevin secures the new ropes after finishing up on track 34.  Looking toward the back of the building on the right note that Toledo is up front more with 1467 next and Red Arrow 5 back infront of good old M37


Shifting cars to flip Red Arrow 5 and Shaker 94



Just observin' what's happening on an operating day






Canopy from afar with beautiful new roof!  Go Team Go!

Canopy zoomed in





Monday, July 20, 2020

Shaker 94 and Red Arrow 73 switch positions!

After the end of regular streetcar service and new operator training on Saturday July 18, 2020 our enthusiastic young people organized the effort to move Shaker Heights Rapid 94 from the shop to the Trolley Display Building and return with Philadelphia Suburban 73 to put in 94' place.
Thursday and Friday Michael Buchta worked into the evening and got the headlight installed in housing on 94's dash.  We had all of the components on hand and Mike did a great job of finishing things up.





66 & 94 arrive at McClane coupled together under the wonderful billboard on I-79




Michael made this close up shots



Locomotive 89 went ahead to the TDB to switch everything around ahead of 94's arrival









Kevin his Dad Doug and Loco 89 were really busy ahead of 73's arrival



94 all tucked in, the back for now


Mike took this photo of the other side.  We still need to apply the decals.




The video showing the two car Center Door Train coming back to the shop

Saturday, July 11, 2020

Progress on the Fairgrounds Canopy

Down at the Museum we have had a trickle of visitors and some very dedicated volunteers operating the cars and giving tours.  The Museum is open Thursday---Sunday.

Kevin and Michael with some help from Laura have been hard at work on the Fairgrounds platform canopy Monday---Wednesday as illustrated with the photos below.  In the shop I have been busy building shelves for the parts from 8042, which is scheduled to have work resume on Monday 7/13.  We have one Operator for an hour person scheduled that day.  The beat goes on...








Michael manned the crane car and the forklift

Kevin welding beams in place.  7/8/2020

Kevin smiling for the camera.



On Wednesday (7/8) Ominous clouds foretell the deluge hit us yesterday.






The other big thing in my sights is Grampa's pet Playtrolley, currently being refurbished by volunteer Tom Pawlesh.
